Sensor LED ceiling lamp Square with motion detector
Flate sensor design light Square LED with motion detector
You have both hands full and cannot reach the light switch? Then simply switch to our LED wall and ceiling lights with integrated high-frequency sensor. They combine the advantages of LED technology with the advantages of a sensor. The special high-frequency sensor is invisibly hidden behind the glass. No matter if wall or ceiling, the sensor works with both types of mounting and is especially suitable for rooms with short dwell times. An even higher cost saving and more comfort by automatic switching on and off of the light. The sensor can be adapted to individual requirements: the light duration ranges from 5 seconds to 10 minutes and the brightness sensitivity from 10 to 500 lux.- 360° detection angle and long range from 1m to 5.5m radius
- LED: 18W 1800lm 3000K (warm white)
- integrated sensor HF technology
- Twilight threshold: 10-500Lux
- Sensor not visible under the opal matt plastic cover
Suitable for: toilet, storage room, hallway, staircase, cellar etc.
Electrical data
Lamp type: LED SMD - not interchangeable
Lamp life: Ø 30.000 hours
power output: 18W
Luminous flux: 1800lm
Colour rendering: CRI >80
Most similar colour temperature: 3000K
Beam angle: 110°.
Light emission: Direct
Symmetry: Symmetric
Dimmable: No
Ballast: LED driver (incl.)
Supply voltage: 220-240V AC
Lamp base connection: plug-in terminal 3-pin; max. 2.5mm²
Sensor: High-frequency detector
Range: Ø up to 11m
Detection angle: 360°.
Switch-off delay: 5 sec. to 24 hrs.
Brightness: 0 - 500 Lux
Energy classes: A++ to A
Housing data
Colour: Alugrey
Housing material: Polycarbonate
Material cover: Polycarbonate Opal
Type of closure: screwed
Protection class: IP20
Protection class: SK II protective insulated
Mark of conformity: CE; RoHS
Temperature range: -15°C to +40°C
Dimensions (mm)
LxWxH: 260x260x44 mm
Lamp type: LED SMD - not interchangeable
Lamp life: Ø 30.000 hours
power output: 18W
Luminous flux: 1800lm
Colour rendering: CRI >80
Most similar colour temperature: 3000K
Beam angle: 110°.
Light emission: Direct
Symmetry: Symmetric
Dimmable: No
Ballast: LED driver (incl.)
Supply voltage: 220-240V AC
Lamp base connection: plug-in terminal 3-pin; max. 2.5mm²
Sensor: High-frequency detector
Range: Ø up to 11m
Detection angle: 360°.
Switch-off delay: 5 sec. to 24 hrs.
Brightness: 0 - 500 Lux
Energy classes: A++ to A
Housing data
Colour: Alugrey
Housing material: Polycarbonate
Material cover: Polycarbonate Opal
Type of closure: screwed
Protection class: IP20
Protection class: SK II protective insulated
Mark of conformity: CE; RoHS
Temperature range: -15°C to +40°C
Dimensions (mm)
LxWxH: 260x260x44 mm
