LED panel ceiling light dimmable 36W warm white 60x60
Quadratic LED light panel in dimmable version
With its height of only 50mm, this flat ceiling lamp can be used in low rooms or under a sail cloth!The luminous surface of the opal plastic panel shines in warm white light (3000K). The LED bulbs are not directly visible and their light effect is perceived as pleasantly uniform and therefore homely. The power consumption is 36W and the luminous flux is up to 4500 lumens.
The LED luminaire is with a phase dimmer dimmable and the included transformer is connected by means of a plug-in system. The luminaire has a UGR<19 (glare value below 19) and is essential for office spaces to ensure glare-free activity at the computer workstation.
LED panel is suitable for: Offices and private rooms such as kitchen, living room, bedroom, bathroom etc.
The delivery includes the LED panel, phase dimmable transformer. A white surface mounting frame is required for mounting and can be ordered optionally.
Material: aluminum
Color: white RAL 9010
Dimensions LED panel: LxWxH:595x595x10mm
Dimensions mounted frame: LxWxH: 600x600x50mm
Voltage: 220-240V AC
Light output: 36W
Light color: 3000K warm white
Beam angle: 120°
Lumen: 4500 lm
Color rendering: >80
Life time L70|B10: 53.000 h
Switching cycles: 30.000 h
Ambient temperature: -20°C to 40°C
Protection class: IP40
Dimmable: Yes
Dimming range: 20-100% of the light output with TRIAC dimmer | Recommendation: use trailing-edge dimming actuator | Flicker component depends on the dimming actuator used and the type of dimming | Flicker-free in undimmed state
Special features: UGR<19 (glare value below 19, suitable for office, glare-free activity at computer workstation).
Indoor use: Yes
Incl. transformer: Yes
Incl. illuminant: Yes
Energy class: A++
The illuminant is not replaceable
Warranty: 5 years
Color: white RAL 9010
Dimensions LED panel: LxWxH:595x595x10mm
Dimensions mounted frame: LxWxH: 600x600x50mm
Voltage: 220-240V AC
Light output: 36W
Light color: 3000K warm white
Beam angle: 120°
Lumen: 4500 lm
Color rendering: >80
Life time L70|B10: 53.000 h
Switching cycles: 30.000 h
Ambient temperature: -20°C to 40°C
Protection class: IP40
Dimmable: Yes
Dimming range: 20-100% of the light output with TRIAC dimmer | Recommendation: use trailing-edge dimming actuator | Flicker component depends on the dimming actuator used and the type of dimming | Flicker-free in undimmed state
Special features: UGR<19 (glare value below 19, suitable for office, glare-free activity at computer workstation).
Indoor use: Yes
Incl. transformer: Yes
Incl. illuminant: Yes
Energy class: A++
The illuminant is not replaceable
Warranty: 5 years
